EasyTier is inherently a decentralized P2P tool where any node can act as a relay server. However, each node's configuration file must be manually edited, which felt somewhat unfamiliar after migrating from Tailscale. Additionally, during the exploration phase, frequent configuration changes are often needed, leading to the decision to deploy EasyTier's Dashboard centrally for unified device management.
Project Repository: https://github.com/easytier/easytier
The official documentation doesn't explicitly provide a method for deploying the config-server separately, but it's actually quite straightforward, as the server component is already included in the downloaded binary file. This article focuses on installation via Docker Compose. For binary installation, please refer to the reference articles below.
Analysis
The dashboard deployment consists of two main parts: a backend RESTful API and a frontend web console. The easytier-web-embed binary found in the Releases provides both. Therefore, running this single binary enables the full functionality.
Let's Get Started
Deploying the API and Web Console
Deploying with Docker is straightforward.
Two ports need to be exposed:
11211/tcp: API interface, HTTP22020/udp: For communication between clients (easytier-core) and the server.
Volume mapping is required for the container's /app folder to persist data.
The Compose file is as follows:
services:
easytier:
restart: always
hostname: easytier
volumes:
- /opt/easytier/api:/app
ports:
- "127.0.0.1:11211:11211"
- "22020:22020/udp"
environment:
- TZ=Asia/Shanghai
image: easytier/easytier:latest
entrypoint: easytier-web-embed
The image here is the same one used for deploying the client via Docker in the official documentation. The default entrypoint is easytier-core, so running the web API requires specifying the entrypoint as easytier-web-embed.
Since the API interface requires HTTPS, the 11211 port is not directly exposed to the public internet here. Instead, it's bound to 127.0.0.1 and then exposed via a reverse proxy with HTTPS.
Setting up Reverse Proxy
I use 1Panel, so I simply created a new site in the panel and set up a reverse proxy to the configured API port.
Registering a Console Account
After deployment, open https://your-domain.com (if using the built-in console version, adding /web/ is not necessary). Change the 'Api Host' to https://your-domain.com. Ensure there is no trailing "/" in the Api Host URL, otherwise, strange issues may occur. Click 'Register' below to create an account.
Then use this account to log in and access the console.
Client Configuration
Remove all startup parameters for the client, keeping only --config-server udp://your-ip:22020/your-username. Run the easytier-core binary, and the device should appear in the console.
Click the settings button on the right, then click 'Create' to create a network for it. The subsequent steps are the same as in the local GUI mode and won't be detailed here. After saving, select the newly created network from the 'network' dropdown to join it.
Because Docker container data is lost on restart, when deploying the client in Docker, a file must be mapped to the container path /usr/local/bin/et_machine_id to save the machine ID. Otherwise, the network will need to be reconfigured after each restart. Additionally, setting the container's hostname can be used as the device name displayed in the web console.
Here is my compose file for the client:
services:
easytier:
command: '--config-server udp://<ip>:22020/KaguraiYoRoy'
environment:
- TZ=Asia/Shanghai
hostname: truenas
image: easytier/easytier:latest
labels:
com.centurylinklabs.watchtower.enable: 'true'
mem_limit: 0m
network_mode: host
privileged: True
restart: always
volumes:
- >-
/mnt/systemdata/DockerData/easytier/app/et_machine_id:/usr/local/bin/et_machine_id
watchtower:
command: '--interval 3600 --cleanup --label-enable'
environment:
- TZ=Asia/Shanghai
- WATCHTOWER_NO_STARTUP_MESSAGE
image: containrrr/watchtower
restart: always
volumes:
- /var/run/docker.sock:/var/run/docker.sock
References:
